Motogadget mo.unit basic Motorcycle Electrical Control Unit

The Motogadget mo.unit basic is a sophisticated digital control unit designed to simplify and modernise a motorcycle's electrical system. Acting as the central control hub for the vehicle electrics, it can replace conventional fuses, relays and numerous individual wiring components, making it ideal for custom motorcycles, restorations and streamlined electrical builds.

The mo.unit basic uses reliable, wear-free semiconductor switches to control the motorcycle's electrical components and can operate with either push-button controls or conventional switch-type handlebar controls. With 12 inputs and 10 outputs, it provides extensive control over lighting, indicators, ignition, starter, horn and other electrical accessories.

Unlike the mo.unit blue, the mo.unit basic does not include Bluetooth or smartphone connectivity, making it an excellent choice for riders and builders who want the core functionality of the Motogadget electrical control system without wireless features.

Key Features

• Central digital control unit for motorcycle electrical systems.
• 12 inputs and 10 outputs.
• Compatible with conventional switches or 4 and 5-button push-button controls.
• Replaces conventional electrical fuses.
• Wear-free high-performance semiconductor switching technology.
• Helps reduce the number of relays, connectors and individual electrical components required in the wiring harness.
• Integrated alarm system.
• Integrated load-independent indicator relay.
• Integrated digital horn relay.
• Two configurable auxiliary outputs - AUX1 and AUX2.
• Complete electrical system diagnostic functionality.
• Detection of defective lighting components.
• Waterproof and vibration-resistant IP69 construction.

Lighting & Indicator Functions

• Load-independent indicator control.
• Hazard warning light function.
• Adjustable indicator position-light function.
• Time-controlled automatic indicator cancellation.
• Distance-controlled indicator cancellation when used with a compatible speedometer sensor.
• Integrated parking light function.
• Headlight flash function.
• Low and high beam operation from a single button.
• Hyperbeam function supporting 200W high beam plus low beam.
• Brake light modulator with eight adjustable modes.
• Emergency brake light function.
• Garage light function.

Electrical & Control Functions

• Starter relay function for starters with magnetic switches - maximum 30A.
• Intelligent electrical load shut-off during engine starting.
• Integrated digital horn relay.
• Fan run-on function.
• Two configurable auxiliary outputs.
• Electrical system diagnostics.
• Detection of defective light sources.

Inputs

• Ignition lock +12V or Motogadget mo.lock.
• Left indicator.
• Right indicator.
• Light.
• Starter.
• Horn.
• Brake light.
• Kill switch.
• Side stand.
• LIN bus.
• AUX1.
• AUX2.

Outputs

• Left indicator.
• Right indicator.
• Low beam.
• High beam.
• Starter.
• Horn.
• Brake light.
• Ignition.
• AUX1 universal output.
• AUX2 universal output.

Specifications

• Dimensions: 90 x 53 x 30 mm
• Weight: Approximately 180 g
• Operating Voltage: 9V-15V
• Operating Temperature: -20°C to +80°C
• Protection Rating: IP69
• Mounting: 2 x M5 screws
• Mounting Hole Distance: 74 mm
• Inputs: 12
• Outputs: 10

Package Includes

• 1 x Motogadget mo.unit basic.
• 1 x M5 positive terminal screw.
• 2 x M5 mounting screws with nuts and washers.

Optional Accessories

The following components can be purchased separately where required for your installation:

• Battery connection cable.
• Battery connection cable with vehicle main fuse.
• Complete vehicle wiring cable kit.
• Bus terminal earth connector.
• Motogadget mo.lock ignition lock.
• Speedometer sensor with two neodymium magnets.

mo.unit basic vs mo.unit blue

The mo.unit basic provides the core motorcycle electrical control functions of the Motogadget system but does not include Bluetooth connectivity or smartphone app functions. Riders requiring features such as smartphone configuration, Keyless-Go, trip logging and app-based vehicle management should consider the Motogadget mo.unit blue instead.

For custom builders and riders looking to create a clean, compact and highly capable motorcycle electrical system without smartphone connectivity, the Motogadget mo.unit basic provides an impressive combination of functionality, reliability and premium German engineering.
